Electronics - Basics "compact" (MBC)

Experiment subjects:

Semiconductors
EOC 01.01 PTC resistor
EOC 01.02 Automatic protection against overheating
EOC 01.05 LDR (Light-dependent resistor)
EOC 01.06 Model of a light meter

Diodes
EOC 03.01 Silicon diode
EOC 03.02 Characteristic lines of semiconductor diodes
EOC 03.03 Forward voltage of a silicon diode
EOC 03.05 Light-emitting diode (LED)
EOC 03.06 Forward voltage of a LED

Transistors
EOC 04.01 Does a transistor consist of two diodes? (NPN)
EOC 04.02 The transistor works as a switch (NPN)
EOC 04.05 The transistor works as an amplifier
EOC 04.06 Light-triggered alarm
EOC 04.08 Burglar alarm using trap wire
EOC 04.09 Automatic lighting
EOC 04.10 Alarm triggered by a light barrier

Capacitors
EOC 05.01 A capacitor can store charges
EOC 05.03 Charging a capacitor
EOC 05.04 Discharging a capacitor
EOC 05.05 A capacitor supplies base current
EOC 05.06 Capacitance
EOC 05.07 Time switch
EOC 05.08 A capacitor blocks DC
EOC 05.09 Capacitor in an AC circuit
EOC 05.10 One-way rectification
EOC 05.14 Charged capacitors connected in series

For the experiments marked with *, additional parts or devices are required for the ‘Electronics - Basic’ equipment set
